ASME U Seamless Carbon Steel Boiler Tube ST 37.8 Pipa Baja Karbon
Product Details
| Nama Produk: | Tabung Boiler Seamless Baja Karbon | Aplikasi: | Untuk boiler bertekanan tinggi, sedang, dan bertekanan rendah |
|---|---|---|---|
| Standar: | DIN17175 | Bahan: | ST35.8 |
| Menyoroti |
Tabung Boiler Baja Karbon ASME,Tabung Boiler Baja Karbon ST 37.8,Pipa Baja Karbon ST 37.8 |
||
Product Description
ASME U Seamless Carbon Steel Boiler Tube St 37.8 Pipa Baja Karbon
Standar Produksi: GB/T20409-2006
Benang Internal Boiler tekanan tinggi Tabung senapanadalah salah satu jenis proses endofragma garis spiral pipa baja mulus.Aplikasi utama pada dinding pendingin air boiler utilitas kapasitas.Biasanya dengan tabung fluoresen yang menggunakan perbandingan, ia dapat mempertahankan kondisi ledakan nuklir di bawah kondisi operasi beban demam tinggi, sehingga menghindari pengiriman ledakan kondisi pembuatan film, mencegah pipa terbakar, memperpanjang umur layanan pipa.
SteelGrade: 20G, 20MNG, 25MNG, 12CRMOG, 15CRMOG, SA210A1, SA210C, SA213T2/T12, WB36, T91, T11,
P11,P22,P92,P5,P9,R102,CR5MO,16MO3,12CR2MOWVTIB
Nomor Utas:4 iga/6 iga/8 iga/12 iga
Parameter Kimia & Mekanik
| Nilai | C | M N | Si | Cr | mo | S | P |
| 20G | 0,17~0,23 | 0,35~0,65 | 0,17~0,37 | --- | --- | 0.020 | 0,025 |
| 20MnG | 0,17~0,23 | 0,70~1,00 | 0,17~0,37 | --- | --- | 0.020 | 0,025 |
| 25MnG | 0,22~0,29 | 0,70~1,00 | 0,17~0,37 | --- | --- | 0.020 | 0,025 |
| 12CrMoG | 0,08~0,15 | 0,40~0,70 | 0,17~0,37 | 0,40~0,70 | 0,40~0,55 | 0.020 | 0,025 |
| 15CrMoG | 0,12~0,18 | 0,40~0,70 | 0,17~0,37 | 0,80~1,10 | 0,40~0,55 | 0.020 | 0,025 |
| SA-210A1 | 0.27 | 0.93 | 0,10 | --- | --- | 0,035 | 0,035 |
| SA-210C | 0,35 | 0,29~1,06 | 0,10 | --- | --- | 0,035 | 0,035 |
| SA-213T2 | 0,10~0,20 | 0,30~0,61 | 0,10~0,30 | 0,50~0,81 | 0,44~0,65 | 0,025 | 0,025 |
| SA-213T12 | 0,05~0,15 | 0,30~0,61 | 0,50 | 0,80~1,25 | 0,44~0,65 | 0,025 | 0,025 |
| Nilai | T(MPa) | Y(MPa) | E(%) | Kekerasan |
| 20G | 410~550 | 245 | 24 | --- |
| 20MnG | 415 | 240 | 22 | --- |
| 25MnG | 485 | 275 | 20 | --- |
| 12CrMoG | 410~560 | 205 | 21 | --- |
| 15CrMoG | 440~640 | 235 | 21 | --- |
| SA-210C | 415 | 255 | 30 | 143HBW |
| SA-210A1 | 485 | 275 | 30 | 179HBW |
| SA-213T2 | 415 | 205 | 30 | 163HBW |
| SA-213T12 | 415 | 220 | 30 | 163HBW |
| Ukuran Tabung untuk Penukar Panas & Kondensor & Boiler | |||||||||||
| Diameter luar | BWG | ||||||||||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||||
| Tebal Dinding mm | |||||||||||
| 0,508 | 0,71 | 0,89 | 1.24 | 1.65 | 2.11 | 2.77 | 3.40 | ||||
| mm | inci | Berat kg/m | |||||||||
| 6.35 | 1/4 | 0,081 | 0.109 | 0.133 | 0,174 | 0.212 | |||||
| 9.53 | 3/8 | 0,126 | 0,157 | 0.193 | 0.257 | 0,356 | 0,429 | ||||
| 12,7 | 1/2 | 0.214 | 0.263 | 0,356 | 0,457 | 0.612 | 0,754 | ||||
| 15.88 | 5/8 | 0,271 | 0,334 | 0,455 | 0,588 | 0,796 | 0.995 | ||||
| 19.05 | 3/4 | 0,327 | 0,405 | 0,553 | 0,729 | 0,895 | 1.236 | ||||
| 25.4 | 1 | 0,44 | 0,546 | 0,75 | 0,981 | 1.234 | 1.574 | 2.05 | |||
| 31.75 | 1 1/4 | 0,554 | 0,688 | 0,947 | 1.244 | 1.574 | 2.014 | 2.641 | |||
| 38.1 | 1 1/2 | 0,667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |||
| 44.5 | 1 3/4 | 1,342 | 1.774 | 2.244 | 2.894 | 3.5 | |||||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||||
| 88.9 | 3 1/2 | 2,729 | 3.609 | 4.584 | 5.974 | 7.27 | |||||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 | ||||||
| Bentuk Tabung: Lurus & U-tikungan & Bersirip & Melingkar | |||||||||||
| Tabung Baja Tahan Karat: A/SA213, A/SA249, A/SA268, A/SA269, A/SA789, EN10216-5, A/SA688, B/SB163, JIS-G3463, GOST9941-81. | |||||||||||
| Tabung Baja Karbon & Paduan: A/SA178, A/SA179, A/SA192, A/SA209, A/SA210, A/SA213, A.SA214 |
|||||||||||
Sertifikasi
