Grade A ERW Grade 430 SS Steel Welded Tubing Untuk Teknik Limbah
Product Details
| Bahan: | TP304 TP304L TP316 TP316L | Menyelesaikan: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, petrokimia, pertambangan, makanan, kertas, gas dan industri cair | membentuk: | tabung dilas |
| OD: | 15.9mm hingga 406.4mm | WT: | 0.89mm hingga 5mm |
| Menyoroti |
ERW Grade SS Steel Tubing,Grade A Steel Welded Tubing,ERW Grade Steel Welded Tubing |
||
Product Description
Grade A ERW Ss Stainless Steel Welded Tubine Grade 430 Untuk Teknik Limbah
informasi produk
| Aplikasi: | a) Untuk transportasi fluida dan gas |
| b) Struktur dan permesinan | |
| c) Pipa penukar panas dll | |
| Keuntungan : | a) Permukaan akhir yang superior |
| b) Sifat mekanik yang lebih baik | |
| c) Dimensi yang lebih tepat | |
| d) Metode inspeksi dan peralatan inspeksi yang sempurna | |
| Harga Barang: | FOB, CFR, CIF atau sebagai negosiasi |
| Pembayaran : |
T/T, LC atau sebagai negosiasi |
| Keterangan | ||
| Barang |
Tabung Las Stainless Steel Food Grade 430 | |
| Kualitas baja | 300 seri | |
| Standar |
ASTM A213,A312,ASTM A269,ASTM A778,ASTM A789,DIN 17456, DIN17457,DIN 17459,JIS G3459,JIS G3463,GOST9941,EN10216, BS3605, GB13296 |
|
| Bahan |
304.304L,309S,310S,316.316Ti,317.317L,321.347.347H,304N,316L, 316N,201, 202 |
|
| Permukaan | Poles, anil, pengawetan, cerah | |
| Jenis | canai panas dan canai dingin | |
| pipa / tabung bulat stainless steel | ||
| Ukuran | ketebalan dinding | 1mm-150mm (SCH10-XXS) |
| Diameter luar | 6mm-2500mm (3/8"-100") | |
| pipa/tabung persegi stainless steel | ||
| Ukuran | ketebalan dinding | 1mm-150mm (SCH10-XXS) |
| Diameter luar | 4mm * 4mm-800mm * 800mm | |
| pipa / tabung persegi panjang stainless steel | ||
| Ukuran | ketebalan dinding | 1mm-150mm (SCH10-XXS) |
| Diameter luar | 6mm-2500mm (3/8"-100") | |
| Panjang | 4000mm, 5800mm, 6000mm, 12000mm, atau sesuai kebutuhan | |
Standar ASTM A249 :
| Ukuran OD | Dinding Nominal | Diameter luar | Panjang | dinding |
| 1/2" (12.7) | 0,065" (1,65)/0,049" (1,25) | +/-0,005 (0,13) | +1/8" (3.18) - 0 | +/-10.0% |
| 3/4" (19.1) | 0,065" (1,65)/0,049" (1,25) | +/-0,005 (0,13) | +1/8" (3.18) - 0 | +/-10.0% |
| 1" (25,4) | 0,065" (1,65)/0,049" (1,25) | +/-0,005 (0,13) | +1/8" (3.18) - 0 | +/-10.0% |
| 1-1/2" (38.1) | 0,065" (1,65)/0,049" (1,25) | +/-0,008" (0,20) | +1/8" (3.18) - 0 | +/-10.0% |
| 2" (50.8) | 0,065" (1,65)/0,049" (1,25) | +/-0,008" (0,20) | +1/8" (3.18) - 0 | +/-10.0% |
| 2-1/2" (63.5) | 0,065" (1,65) | +/-0,010" (0,25) | +1/8" (3.18) - 0 | +/-10.0% |
| 3" (76.2) | 0,065" (1,65) | +/-0,010" (0,25) | +1/8" (3.18) - 0 | +/-10.0% |
| 4" (101.6) | 0,083" (2.11) | +/-0,015" (0,38) | +1/8" (3.18) - 0 | +/-10.0% |
| 6" (152.4) | 0,083" (2.11) | +/-0,030" (0,76) | +1" (25,4) - 0 | +/-10.0% |
| 6" (152.4) | 0,109" (2,77) | +/-0,030" (0,76) | +1" (25,4) - 0 | +/-10.0% |
| 8" (203.2) | 0,109" (2,77) | +0,061" (1,55)/-0,031" (0,79) | +1" (25,4) - 0 | +/-10.0% |
Kelas bahan:
| Standar Amerika | TP304, TP304L, TP310S, TP316, TP316L, TP316Ti, TP321, TP347, 904L, S31803 Dll |
| Standar Eropa | 1.4301 , 1.4306 , 1.4845 , 1.4401 , 1.4404 , 1.4571 , 1.4541 , 1.4550 , 1.4539 , 1.4462 Dll |
| Standar Jerman | X5CrNi18-10, X2CrNi19-11, X12CrNi25-21, X5CrNi17-12-2, X5CrNi17-12-3, X2CrNiMo18-14-3, X6CrNiTi18-10, X6CrNiTb18-10 Dll |
1 .OD (Diameter Luar): 15.9mm hingga 406.4mm
2 .WT ( Tebal Dinding ) : 0.89mm hingga 5mm
3 .Panjang : Sesuai dengan kebutuhan pelanggan
4 .Standar:ASTM A312;ASTM A269;ASTM A789;ASTM A790 dll
5 .Metode Proses:ERW, EFW dll
