Tabung Baja Boiler SA192 Tekanan Tinggi Untuk Pemeliharaan Pembangkit Listrik
Product Details
| Nama Produk: | Tabung Boiler Baja Karbon Mulus | Aplikasi: | Untuk boiler bertekanan tinggi, sedang, dan bertekanan rendah |
|---|---|---|---|
| Standar: | ASTM A192 Tabung Baja Tekanan Tinggi | Teknik: | Mulus |
| Bentuk bagian: | Bulat | Bahan: | Baja karbon |
| Menyoroti |
Tabung Baja SA192 Tekanan Tinggi,Tabung Baja Pembangkit Listrik SA192,ASTM A192 Tabung Baja Tekanan Tinggi |
||
Product Description
Tabung Boiler Baja Karbon Seamless Tekanan Tinggi SA192 Untuk Pemeliharaan Pembangkit Listrik
Tabung Baja Karbon SMLS A192 / SA192 Untuk Boiler Tekanan Tinggi, Menengah, Rendah Dan Tujuan Tekanan
Rincian:
Standar: ASTM A192/SA192SMLS
Ukuran: (mm)
Dimensi Keluar: 12,7mm – 114,3mm
Tebal Dinding: 0.8mm - 15mm
Panjang: Tetap (6m,9m,12,24m) atau panjang normal (5-12m)
Keterangan:
ASTM ASTM A192 SMLS
Tabung Boiler Baja Karbon Mulus Untuk Layanan Tekanan Tinggi.
kelas baja:
Kelas A
Sedang mengemas:
Miring/lukisan hitam/topi plastik/dalam bundel/strip baja/perlindungan kayu
Inspeksi dan Uji:
Pemeriksaan Komposisi Kimia, Uji Sifat Mekanik (Kekuatan Tarik, Kekuatan Hasil, Perpanjangan, Pembakaran, Perataan, Pembengkokan, Kekerasan, Uji Dampak), Uji Permukaan dan Dimensi, Uji Nodestruktif, Uji Hidrostatik.
Pengobatan permukaan:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
Tanda:
Seperti yang diminta.
Kondisi pengiriman:
Anil, Normalisasi, Normalisasi, dan Tempered
Komposisi kimia:
| Produk | Ttem | Nilai | Komposisi kimia | |||||||
| C | Si | M N | P.≤ | S.≤ | Cr | Ni | yang lain | |||
| Baja karbon | 1 | 10 | 0,07/0,13 | 0.17/0.37 | 0.35/0.65 | 0,03 | 0,03 | 0,15 | 0.30 | Cu≤0,25 |
| 2 | 20 | 0.17/0.23 | 0.17/0.37 | 0.35/0.65 | 0,03 | 0,03 | 0,25 | 0.30 | Cu≤0,25 | |
| 3 | A179 | 0,06/0,18 | - | 0.27/0.63 | 0,03 | 0,03 | - | - | - | |
| 4 | A192 | 0,06/0,18 | 0,25 | 0.27/0.63 | 0,03 | 0,03 | - | - | - | |
Peralatan mekanis:
| Barang | tanda | properti tarik | Kekerasan | ||||
| Kekuatan ekstensi Rm Mpa | Kekuatan Hasil Lebih Rendah Rel atau Rp0.2 MPa | menurunkan kekuatan hasil ReL atau Rp0.2 Mpa | |||||
| Ketebalan | Ketebalan | ||||||
| 16 | >16 | <5.1 | 5.1 | ||||
| ≥ | ≤ | ||||||
| 1 | 10 | 335~475 | 205 | 195 | 24 | - | - |
| 2 | 20 | 410~530 | 245 | 235 | 20 | - | - |
| 3 | A179 | 325 | 180 | 35 | - | - | |
| 4 | A192 | 325 | 180 | 35 | 77HRB | 137HB | |
Aplikasi:
1, Untuk evaporator, penukar panas, kondensor, peralatan perpindahan panas dan pipa serupa.
2, Banyak digunakan di bidang perawatan mekanik, industri petrokimia, transportasi dan bidang konstruksi
3, tujuan struktural biasa dan tujuan struktural mekanik, misalnya di bidang konstruksi, bantalan tumpu dll;
4, Transportasi cairan dalam proyek dan peralatan besar, misalnya transportasi air, minyak, gas, dll
5, Dapat digunakan dalam boiler tekanan rendah dan menengah untuk pengangkutan cairan, misalnya tabung uap, tabung asap besar, tabung asap kecil, tabung pembangkit dll
Inspeksi dan Uji:
Pemeriksaan Komposisi Kimia, Uji Sifat Mekanik (Kekuatan Tarik, Kekuatan Hasil,
Perpanjangan, Pembakaran, Perataan, Pembengkokan, Kekerasan, Uji Dampak), Uji Permukaan dan Dimensi, Uji Tidak Merusak, Uji Hidrostatik.
Pengobatan permukaan:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
