Tabung Boiler Seamless Baja Karbon SA210 Dipernis Untuk Penukar Panas
Product Details
| Kualitas baja: | A210 A1 | Standar: | SEPERTI SAYA |
|---|---|---|---|
| Aplikasi: | Boiler & penukar panas, Superheater, Reheater, Pemanas awal udara, Economizer | OD: | 2.0” |
| Menyoroti |
Tabung Boiler Mulus yang Dipernis,Tabung Boiler Mulus Untuk Penukar Panas,Tabung Boiler Seamless Baja Karbon |
||
Product Description
ASME Standard SA210 A1 Tabung Boiler Seamless Baja Karbon OD 2.0"
| Karbon | kromiun | Suhu rendah | Besi tahan karat | Rangkap | Tembaga & Perunggu | Titanium | Paduan Ni | ||
| SA178-A | SA213-T1 | SA333-Gr.1 | SA213 | TP316L | A789-S31803 | SB111-C70600 | SB338-GR.1 | SB163 | NO2200 |
| SA178-C | SA213-T11 | SA333-Gr.3 | SA249 | TP316H | A789-S32205 | SB111-C71500 | SB338-GR.2 | SB167 | NO2201 |
| SA179 | SA213-T12 | SA333-Gr.6 | SA268 | TP316Ti | A789-S32750 | SB111-C71640 | SB338-GR.5 | SB444 | NO8020 |
| SA192 | SA213-T22 | SA333-Gr.7 | SA269 | TP316LN | A789-S32760 | SB111-C68700 | SB338-GR.7 | SB514 | NO6022 |
| SA209-T1 | SA213-T5 | SA333-Gr.8 | SA376 | TP321 | A789-S32707 | SB111-C44300 | SB338-GR.9 | SB619 | N10276 |
| SA209-T1a | SA213-T9 | SA334-Gr.1 | TP304 | TP321H | A789-S32304 | SB338-GR.12 | SB622 | NO4400 | |
| SA209-T1b | SA213-T91 | SA334-Gr.3 | TP304L | TP347 | A789-S31500 | SB626 | NO6600 | ||
| SA210-A1 | SA334-Gr.6 | TP304H | TP347H | S31254 | SB674 | NO6601 | |||
| SA210-C | SA334-Gr.7 | TP304N | TP405 | 254MA | SB677 | NO6625 | |||
| SA214 | SA334-Gr.8 | TP310H | TP409 | 17-4PH | SB704 | NO690 | |||
| SA513 MT 1010 | TP310S | TP410 | 17-7PH | SB705 | NO8800 | ||||
| SA513 MT 1015 | TP309S | TP430 | 15-7PH | N1001 | NO8810 | ||||
| SA513 MT 1020 | TP317 | TP439 | N10665 | NO8811 | |||||
| TP317L | TP444 | N10675 | NO8825 | ||||||
| TP348 | TP446 | TP904L | |||||||
| TP347HFG | |||||||||
| Ukuran Tabung untuk Penukar Panas & Kondensor & Boiler | |||||||||
| Diameter luar | BWG | ||||||||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| Tebal Dinding mm | |||||||||
| 0,508 | 0,71 | 0,89 | 1.24 | 1.65 | 2.11 | 2.77 | 3.40 | ||
| mm | inci | Berat kg/m | |||||||
| 6.35 | 1/4 | 0,081 | 0.109 | 0.133 | 0,174 | 0.212 | |||
| 9.53 | 3/8 | 0,126 | 0,157 | 0.193 | 0.257 | 0,356 | 0,429 | ||
| 12,7 | 1/2 | 0.214 | 0.263 | 0,356 | 0,457 | 0.612 | 0,754 | ||
| 15.88 | 5/8 | 0,271 | 0,334 | 0,455 | 0,588 | 0,796 | 0.995 | ||
| 19.05 | 3/4 | 0,327 | 0,405 | 0,553 | 0,729 | 0,895 | 1.236 | ||
| 25.4 | 1 | 0,44 | 0,546 | 0,75 | 0,981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0,554 | 0,688 | 0,947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0,667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1,342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2,729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 | ||||
ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Komposisi Kimia dan Sifat Mekanik
| Nilai | Komposisi kimia% | ||||||||
| C | Si | M N | P, S Maks | Cr | mo | Ni Max | V | Al Max | |
| T2 | 0,10~0,20 | 0,10~0,30 | 0,30~0,61 | 0,025 | 0,50~0,81 | 0,44~0,65 | – | – | – |
| T11 | 0,05~0,15 | 0.50~1.00 | 0,30~0,60 | 0,025 | 1,00~1,50 | 0,44~0,65 | – | – | – |
| T12 | 0,05~0,15 | Maks 0,5 | 0,30~0,61 | 0,025 | 0,80~1,25 | 0,44~0,65 | – | – | – |
| T22 | 0,05~0,15 | Maks 0,5 | 0,30~0,60 | 0,025 | 1,90~2,60 | 0,87~1,13 | – | – | – |
| T91 | 0,07~0,14 | 0,20~0,50 | 0,30~0,60 | 0,02 | 8.0~9.5 | 0,85~1,05 | 0.4 | 0.18~0.25 | 0,015 |
| T92 | 0,07~0,13 | Maks 0,5 | 0,30~0,60 | 0,02 | 8.5~9.5 | 0,30~0,60 | 0.4 | 0,15~0,25 | 0,015 |
| Nilai | Komposisi kimia% | Peralatan mekanis | |||||||
| W | B | Nb | N | T. S | Y.P | Pemanjangan | Kekerasan | ||
| T2 | – | – | – | – | 415MPa | 205MPa | 30% | 163HBW (85HRB) | |
| T11 | – | – | – | – | 415MPa | 205MPa | 30% | 163HBW (85HRB) | |
| T12 | – | – | – | – | 415MPa | 220MPa | 30% | 163HBW (85HRB) | |
| T22 | – | – | – | – | 415MPa | 205MPa | 30% | 163HBW (85HRB) | |
| T91 | – | – | 0,06~0,10 | 0,03~0,07 | 585MPa | 415MPa | 20% | 250HBW(25HRB) | |
| T92 | 1.50~2.00 | 0,001~0,006 | 0,04~0,09 | 0,03~0,07 | 620MPa | 440MPa | 20% | 250HBW(25HRB) | |
ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Toleransi
| Diameter luar | Toleransi OD | Toleransi WT | Toleransi Ovalitas | Toleransi Panjang Potong |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15% | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD 38, 1 mm | ± 0, 13 mm | ± 10% | maks, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD 88, 9 mm | ± 0, 25 mm | ± 10% | maks, 2, 41 mm | + 4, 76 mm, – 0 mm |
- T11 Alloy Steel Tube untuk pembangkit listrik, minyak bumi, dan layanan suhu tinggi lainnya
- T22 Alloy Steel Tube untuk pembangkit listrik, minyak bumi, dan layanan suhu tinggi lainnya
- Tabung Baja Paduan T5 untuk minyak bumi
- Tabung Baja Paduan T9 untuk minyak bumi
- T91 Alloy Steel Tube untuk pembangkit listrik
- T92 Alloy Steel Tube untuk pembangkit listrik
- T1 Alloy Steel Tube untuk penggantian dan perbaikan boiler
- Tabung SA209 T1 untuk Boiler Manufaktur
- ASTM A213 / ASME SA213 T5 Tabung Baja Paduan untuk Pemanas Super
- ASTM A213 / ASME SA213 T5 Tabung Baja Paduan untuk Penukar Panas
