Customized Carbon Steel Sa210 A1 Cold - Ditarik Dan Cold - Rolled Seamless Boiler Tubes
Product Details
| Besi kelas: | ASTM, SA192 | Permukaan: | Hitam terang |
|---|---|---|---|
| Aplikasi: | Boiler & Heat Exchanger, Superheater, Reheater, Preheater Udara, Economizer, Steam Drum, Manifol | OD: | 6-630mm |
| WT: | 1-60mm | Panjang: | 6000mm |
| Bentuk bagian: | Bulat | Pelabuhan: | Zhangjiagang, Shanghai |
| Menyoroti |
Cold Rolled Seamless Boiler Tubes,Customized Seamless Boiler Tubes,Cold Drawn Seamless Boiler Tubes |
||
Product Description
Customized Carbon Steel Sa210 A1 Cold - Ditarik Dan Cold - Rolled Seamless Boiler Tubes
Apa perbedaan antara pipa tanpa jahitan dan pipa tanpa jahitan?
Pipa tanpa jahitan diproduksi dengan mengekstrusi logam ke panjang yang diinginkan; oleh karena itu pipa ERW memiliki sendi las di bagian penampangnya,sementara pipa tanpa jahitan tidak memiliki sendi di bagian penampangnya sepanjang panjangnya. dll.
Tabung dan Pipa Baja Tulang Besi Bulat ASTM A192
Aplikasi:
Untuk boiler, superheater,
Penukar panas,
Boiler tekanan tinggi,
Boiler uap
Kondensator dingin dan layanan tekanan tinggi,
Layanan suhu tinggi untuk konstruksi boiler
Cara pembuatan:
Tabung diproduksi dengan proses yang lancar dan baik hot finish maupun cold finish dapat diterapkan. Boiler tabung baja dan pipa adalah kekuatan kami di pasar dunia untuk AS, pasar Timur Tengah.
Pengolahan panas:
Tabung yang sudah selesai panas tidak perlu dirawat panas.Tabung Cold Finished dirawat panas setelah melewati akhir Cold Finishing pada suhu 1200°F ((650°C) atau lebih tinggi
Kelas baja SA192 Komposisi Kimia & Sifat Mekanis
|
C
|
Mn
|
P
|
S
|
Ya.
|
Kekuatan tarik
|
Titik Yeild
|
Perpanjangan
|
|
0.06-0.18
|
0.27-0.63
|
0.035Max
|
0.035Max
|
0.25Max
|
min ksi[Mpa] 47[325]
|
Min ksi[Mpa] 26[180]
|
≥ 35%
|
Kekerasan
|
Kekerasan Brinell
|
Nomor Kekerasan Rockwell
|
|
WT≥0,200in ((5,1mm)
|
WT<0,200in ((5,1mm)
|
|
137HRB
|
77HRB
|
KONTROL KUALITAS
1~ Pemeriksaan bahan baku yang masuk
2~ Pengelompokan bahan baku untuk menghindari campuran kelas baja
3~ Pemanasan dan Pencakar ujung untuk menggambar dingin
4~ Menggambar dingin dan penggulung dingin, pemeriksaan di jalur
5~ Pengolahan panas, +A, +SRA, +LC, +N, Q+T
6~ Perataan-Potong ke panjang yang ditentukan-Pengukuran selesai
7~ Pengujian mekanik di laboratorium sendiri dengan kekuatan tarik, kekuatan hasil, elongasi, kekerasan, dampak, struktur mikro dll
8~ Pengemasan dan Pengepakan.
Teknologi Energi Hua Dongadalah salah satu pemasok yang dapat diandalkan dan paling terkemuka dariASTM A192Kami ingin mendengar dari Anda. kami ingin mendengar dari Anda. kami ingin mendengar dari Anda.
