Tabung Sirip Boiler Ganda untuk Penggunaan Boiler Uap dan Pembangkit Listrik dengan Transfer Panas Tinggi
Product Details
| Jenis: | Sirkulasi Alam | Struktur: | Tabung api dan tabung air |
|---|---|---|---|
| Tekanan: | Tekanan Rendah / Tinggi | Gaya: | Vertikal |
| Bahan bakar: | Biomassa, tembakan batu bara | Keluaran: | Uap |
| Berat: | 5000 kg | OD Tabung Dasar: | 25,4 mm ~ 1600mm |
| Ketebalan tabung dasar: | 2,5 mm ~ 40 mm | Tinggi sirip: | 0,5 mm ~ 20,0 mm |
| Ketebalan sirip: | 0,5 mm ~ 3,0 mm | Pitch sirip: | 5 mm ~ 25,4 mm |
| Bahan: | Baja karbon, baja paduan, baja tahan karat | Length: | 0<L≤ 12000 |
| Pipa dasar: | dilas atau mulus | ||
| Menyoroti |
Tabung Sirip Boiler Ganda,Tabung Penukar Panas Boiler Uap,Tabung Sirip Tipe-H Pembangkit Listrik |
||
Product Description
Elemen penukar panas tabung bersirip tipe-H mempertahankan kapasitas tinggi untuk transfer panas, memiliki sifat pembersihan diri yang unggul, dan mempertahankan kemampuan untuk melakukan pemulihan panas limbah gas buang dalam renovasi boiler. Koefisien transfer panas konvektif berbanding lurus dengan jarak sirip, tetapi berbanding terbalik dengan tinggi sirip dan lebar sirip.
- Efisiensi transfer panas tinggi
- Performa anti-aus dan anti-fouling yang sangat baik
- Sifat pembersihan diri yang unggul
- Efektif untuk pemulihan panas limbah gas buang
- Desain yang dapat disesuaikan tersedia
Tabung bersirip tipe-H kami berasal dari tabung bersirip persegi panjang dengan struktur alur unik pada permukaan sirip. Produk dapat dimodifikasi sesuai dengan kebutuhan pelanggan, dirancang untuk keselamatan, keandalan, dan efisiensi di ruang kecil.
| Item | Rentang |
|---|---|
| O.D. Tabung Dasar (mm) | 25.4 mm ~1600mm |
| Ketebalan Tabung Dasar (mm) | 2.5 mm ~40 mm |
| Tinggi Sirip (mm) | 0.5 mm ~20.0 mm |
| Ketebalan Sirip (mm) | 0.5 mm ~3.0 mm |
| Jarak Sirip (mm) | 5 mm ~ 25.4 mm |
| Material | Baja Karbon, Baja Paduan, Baja Tahan Karat |
| Panjang | 0 |
| Produk | Tabung H-fin |
| Pipa Dasar | Dilas atau Tanpa Sambungan |
| Material | Baja karbon, baja paduan, baja tahan karat, paduan non-ferrous dan paduan nikel |
| Aplikasi | H economizer, H evaporator, H superheater, H pemanas udara |
Product Highlights
Tabung Sirip Boiler Ganda/Tabung Penukar Panas untuk Struktur Tabung Api Boiler Uap Deskripsi Produk Elemen penukar panas tabung bersirip tipe-H mempertahankan kapasitas tinggi untuk transfer panas, memiliki sifat pembersihan diri yang unggul, dan mempertahankan kemampuan untuk melakukan pemulihan ...
Pengelasan Frekuensi Tinggi Bagian Ketel Uap Berbahan Bakar Batubara Disesuaikan Stack Economizer Coil
High Frequency Welding Customized Coal Fired Steam Boiler Parts Stack Economizer Coil Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there
Tabung Sirip Spiral Boiler Pengelasan Frekuensi Tinggi Untuk Perpindahan Panas Economizer
High Frequency Welding Boiler Spiral Fin Tube For Economizer Heat Transfer Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there are a huge
Heat Exchanger H Type Boiler Parts Tube Untuk Pembangkit Pembangkit Listrik
High Efficient Heat Exchang H Type High Temperature Resistance Boiler Parts For Utility/Power Station Plant Product Introduce H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface.H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H
Extension Heating Surface Boiler Fin Tube Untuk Boiler Pembangkit Listrik Industri
Energy Saving Extension Heating Surface Boiler Fin Tube For Industrial Power Plant Boiler Product Description H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface. H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H economizer,
